HBE-NC-YAP20A3
Highbright
HBE-NC-YAP20A3
| Quantity: | |
|---|---|
| Sensor Type | 1/2.8 inch CMOS |
| Pixel Count | 2 million |
| Maximum Resolution | 1920 × 1080 |
| Maximum Fill Light Distance | 30m (infrared) |
| Adjustment Angle | Horizontal: 0 °~360 ° Vertical: 0 °~90 ° Rotation: 0 °~360 ° |
| Shell Material | metal+plastic |
| Product Size | 180.0mm × 83.3mm × 114.8mm (length × width × height) |
| Packaging Dimensions | 252mm × 137mm × 113mm (length × width × height) |
| Net Weight | 0.39kg |
| Gross Weight | 0.66kg |
| Installation Method | Wall mounted; Top mounted; Pole installation |
| Power Supply | Standard |
| Working Voltage | DC12V (± 30%) |
| Basic Power Consumption | 2.2W (DC12V) |
| Working Temperature | -30 ℃~+60 ℃ |
| Working Humidity | ≤ 95% |
| Lens | Standard Configuration |
| Lens Type | Fixed Focus |
| Lens Interface | M12 |
| Day Night Conversion | ICR automatic switching |
| Alarm Event | Network disconnection; IP conflict; Mobile detection; Video occlusion; Illegal access |
| Network Interface | 1 (RJ-45 Ethernet port, supporting 10M/100M network data) |
| User Management | Supports up to 20 users |
| Sensor Type | 1/2.8 inch CMOS |
| Pixel Count | 2 million |
| Maximum Resolution | 1920 × 1080 |
| Maximum Fill Light Distance | 30m (infrared) |
| Adjustment Angle | Horizontal: 0 °~360 ° Vertical: 0 °~90 ° Rotation: 0 °~360 ° |
| Shell Material | metal+plastic |
| Product Size | 180.0mm × 83.3mm × 114.8mm (length × width × height) |
| Packaging Dimensions | 252mm × 137mm × 113mm (length × width × height) |
| Net Weight | 0.39kg |
| Gross Weight | 0.66kg |
| Installation Method | Wall mounted; Top mounted; Pole installation |
| Power Supply | Standard |
| Working Voltage | DC12V (± 30%) |
| Basic Power Consumption | 2.2W (DC12V) |
| Working Temperature | -30 ℃~+60 ℃ |
| Working Humidity | ≤ 95% |
| Lens | Standard Configuration |
| Lens Type | Fixed Focus |
| Lens Interface | M12 |
| Day Night Conversion | ICR automatic switching |
| Alarm Event | Network disconnection; IP conflict; Mobile detection; Video occlusion; Illegal access |
| Network Interface | 1 (RJ-45 Ethernet port, supporting 10M/100M network data) |
| User Management | Supports up to 20 users |
