1.1 Cold room structure
Changxue cold room consists mainly of cold room panel, cold room door, condensing unit, evaporator, temperature controller, air curtain, copper pipe and other refrigeration fittings.
1.2 Cold room applications
Cold room is widely used in food industry, medical industry, and other related industry.1.3 Glass cold room features:
1.Temperature range :0/-18 degree C adjustable
2.Size:customized size also acceptable.
3.Functions:quick-freezing,fire-proof are all available
4.Automatic control system
5. Glass display door,with light,shelves and hinge door
1.1 Cold room structure
Changxue cold room consists mainly of cold room panel, cold room door, condensing unit, evaporator, temperature controller, air curtain, copper pipe and other refrigeration fittings.
1.2 Cold room applications
Cold room is widely used in food industry, medical industry, and other related industry.1.3 Glass cold room features:
1.Temperature range :0/-18 degree C adjustable
2.Size:customized size also acceptable.
3.Functions:quick-freezing,fire-proof are all available
4.Automatic control system
5. Glass display door,with light,shelves and hinge door
In cold room projects, the following factors should be fully considered:
Glass door QTY | Cold room size (insulation 75mm) | Cold room size (insulation 100mm) |
2-glass door | 1800*1200*2300mm | 2000*1300*2300mm |
3-glass door | 2800*1200*2300mm | 3000*1300*2300mm |
4-glass door | 3600°1200*2300mm | 3800*1300*2300mm |
5-glass door | 4300*1200*2300mm | 4500*1300*2300mm |
6-glass door | 5000*1200*2300mm | 5200*1300*2300mm |
7-glass door | 5800*1200*2300mm | 6000*1300*2300mm |
8-glass door | 6600*1200*2300mm | 6800*1300*2300mm |
9-glass door | 7300*1200*2300mm | 7500*1300*2300mm |
10-glass door | 8000*1200*2300mm | 8200*1300*2300mm |
In cold room projects, the following factors should be fully considered:
Glass door QTY | Cold room size (insulation 75mm) | Cold room size (insulation 100mm) |
2-glass door | 1800*1200*2300mm | 2000*1300*2300mm |
3-glass door | 2800*1200*2300mm | 3000*1300*2300mm |
4-glass door | 3600°1200*2300mm | 3800*1300*2300mm |
5-glass door | 4300*1200*2300mm | 4500*1300*2300mm |
6-glass door | 5000*1200*2300mm | 5200*1300*2300mm |
7-glass door | 5800*1200*2300mm | 6000*1300*2300mm |
8-glass door | 6600*1200*2300mm | 6800*1300*2300mm |
9-glass door | 7300*1200*2300mm | 7500*1300*2300mm |
10-glass door | 8000*1200*2300mm | 8200*1300*2300mm |
General details of fresh cold room | ||||
Reference dimension(L*W*H) | 6m*4m*2.5m | 8m*5m*2.5m | 10m*6m*2.5m | 11m*6m*3m |
Application | Usually for storage of fresh vegetables and fruits | |||
Temperature | -5°C~+5°C | |||
Power | 380V/50HZ/3Phase (can be customized) | |||
Cold room structure | ||||
Surface metal(Take PPGI on both sides for example) | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI |
Thickness of PU panel | 100mm | 100mm | 100mm | 100mm |
Cold room door(W*H) | Hinged door0.8m*1.8m | Hinged door0.8m*1.8m | Manual sliding door1.5m*2m | Manual sliding door1.5m*2m |
Refrigeration Equipment | ||||
Compressor brand | Germany Bitzer | Germany Bitzer | Germany Bitzer | Germany Bitzer |
Compressor type | Semi-hermetic | Semi-hermetic | Semi-hermetic | Semi-hermetic |
Refrigerant | R404a | R404a | R404a | R404a |
General details of freezer cold room | ||||
Reference dimension(L*W*H) | 6m"4m*2.5m | 6m*4m*2.5m | 6m*6m*2.5m | 6m*8m*2.5m |
Application | Usually for storage of frozen fish,meat and seafood | |||
Temperature | -20°C~-18°C | |||
Power | 380V/50HZ/3Phase (can be customized) | |||
Cold room structure | ||||
Surface metal(Take PPGI on both sides for example) | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI |
Thickness of PU panel | 150mm | 150mm | 150mm | 150mm |
Cold room door(W*H) | Hinged door0.8m*1.8m | Hinged door0.8m*1.8m | Manual sliding door1.5m*2m | Manual sliding door1.5m*2m |
Refrigeration Equipment | ||||
Compressor brand | Germany Bitzer | Germany Bitzer | Germany Bitzer | Germany Bitzer |
Compressor type | Semi-hermetic | Semi-hermetic | Semi-hermetic | Semi-hermetic |
Refrigerant | R404a | R404a | R404a | R404a |
General details of blast freezer | ||||
Reference dimension(L*W*H) | 2.5m*2.5m*2.4m | 4m*3m*2.5m | ||
Application | Usually for fresh fish,fresh meat and fresh seafood | |||
Temperature | -40°C~-35°C | |||
Power | 380V/50HZ/3Phase (can be customized) | |||
Cold room structure | ||||
Surface metal(Take PPGI on both sides for example) | 0.326mm PPGI | 0.326mm PPGI | ||
Thickness of PU panel | 150mm | 150mm | ||
Cold room door(W*H) | Hinged door0.8m*1.8m | Hinged door0.8m*1.8m | ||
Refrigeration Equipment | ||||
Compressor brand | Germany Bitzer | Germany Bitzer | ||
Compressor type | Semi-hermetic | Semi-hermetic | ||
Refrigerant | R404a | R404a |
General details of fresh cold room | ||||
Reference dimension(L*W*H) | 6m*4m*2.5m | 8m*5m*2.5m | 10m*6m*2.5m | 11m*6m*3m |
Application | Usually for storage of fresh vegetables and fruits | |||
Temperature | -5°C~+5°C | |||
Power | 380V/50HZ/3Phase (can be customized) | |||
Cold room structure | ||||
Surface metal(Take PPGI on both sides for example) | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI |
Thickness of PU panel | 100mm | 100mm | 100mm | 100mm |
Cold room door(W*H) | Hinged door0.8m*1.8m | Hinged door0.8m*1.8m | Manual sliding door1.5m*2m | Manual sliding door1.5m*2m |
Refrigeration Equipment | ||||
Compressor brand | Germany Bitzer | Germany Bitzer | Germany Bitzer | Germany Bitzer |
Compressor type | Semi-hermetic | Semi-hermetic | Semi-hermetic | Semi-hermetic |
Refrigerant | R404a | R404a | R404a | R404a |
General details of freezer cold room | ||||
Reference dimension(L*W*H) | 6m"4m*2.5m | 6m*4m*2.5m | 6m*6m*2.5m | 6m*8m*2.5m |
Application | Usually for storage of frozen fish,meat and seafood | |||
Temperature | -20°C~-18°C | |||
Power | 380V/50HZ/3Phase (can be customized) | |||
Cold room structure | ||||
Surface metal(Take PPGI on both sides for example) | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI | 0.326mm PPGI |
Thickness of PU panel | 150mm | 150mm | 150mm | 150mm |
Cold room door(W*H) | Hinged door0.8m*1.8m | Hinged door0.8m*1.8m | Manual sliding door1.5m*2m | Manual sliding door1.5m*2m |
Refrigeration Equipment | ||||
Compressor brand | Germany Bitzer | Germany Bitzer | Germany Bitzer | Germany Bitzer |
Compressor type | Semi-hermetic | Semi-hermetic | Semi-hermetic | Semi-hermetic |
Refrigerant | R404a | R404a | R404a | R404a |
General details of blast freezer | ||||
Reference dimension(L*W*H) | 2.5m*2.5m*2.4m | 4m*3m*2.5m | ||
Application | Usually for fresh fish,fresh meat and fresh seafood | |||
Temperature | -40°C~-35°C | |||
Power | 380V/50HZ/3Phase (can be customized) | |||
Cold room structure | ||||
Surface metal(Take PPGI on both sides for example) | 0.326mm PPGI | 0.326mm PPGI | ||
Thickness of PU panel | 150mm | 150mm | ||
Cold room door(W*H) | Hinged door0.8m*1.8m | Hinged door0.8m*1.8m | ||
Refrigeration Equipment | ||||
Compressor brand | Germany Bitzer | Germany Bitzer | ||
Compressor type | Semi-hermetic | Semi-hermetic | ||
Refrigerant | R404a | R404a |
